4+1+1 phase stable power supply
Core 50A Dr. Mos
High-speed Dual M.2
DDR5 memory, XMP 5600MHz/OC+
Open PCIe x4 slot
Support full protocol WIFI module
TECH SPECS:
CHIPSET INTEL B760
CPU Supports 12th/13th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors
LGA 1700
MEMORY 2x DDR5, Maximum Memory Capacity 96GB
Memory Support DDR5 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz
Supports Intel® XMP 3.0 OC
Supports Dual-Controller Dual-Channel mode
ONBOARD GRAPHICS 1x VGA
*Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz
1x HDMI™port
*HDMI™ port supports up to 4K@30Hz
*Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
EXPANSION SLOT 1x PCIe 4.0 x16 slot
1x PCIe 3.0 x4 slot
STORAGE M.2_1 slot (Key M), type 2242/2280 (supports PCIe 4.0 x4 mode)
M.2_2 slot (Key M), type 2242/2280 (supports PCIe 4.0 x4 mode)
3 x SATA 6Gb/s ports
RAID Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
USB *Front USB (Total 6 ports)
2x USB 3.2 Gen1 Type A
4x USB 2.0
*Rear USB (Total 6 ports)
4x USB 3.2 Gen1 Type A
2x USB 2.0
LAN Realtek® RTL8111H 1G LAN
AUDIO Realtek® ALC897 Codec
5.1-Channel High Definition Audio
INTERNAL I/O 1x 24-pin Power Connector(ATX_PWR)
1x 8-pin Power Connector(CPU_PWR)
1x CPU Fan
2x System Fan
2 x M.2 slots (Key-M)
3x SATA 6Gb/s ports
1x 2-Pin CLR_CMOS
1x 4-Pin BUZZER
1x Front Audio
1x COM_A Port
1x 2-Pin F_PANEL
1x TPM pin header(Support TPM 2.0)
1x 3-Pin SPDIF
1x 12V 4-Pin RGB
LED FEATURE 4x Distributed Debug LED
OPERATING SYSTEM Support for Windows® 11 64-bit, Windows® 10 64-bit
FORM FACTOR M-ATX
245mm x 190mm
