·Stable Power: 8+2+1 phase 50A Dr.MOS power delivery
·Top Performance: Compatible with Ryzen 9 9950X
·High-Speed Connectivity: Dual 10G Type-C ports (front and rear)
TECH SPECS:
CHIPSET AMD® B650 Chipset
CPU (Max Support) Supports AM5 slots
Ryzen7000, Ryzen8000, Ryzen9000 series processors
TDP: 170W
MEMORY 4* DIMM DDR5 memory slots
Supports dual-channel memory technology
Support 4800/5200/5600(OC)6000(OC)/6400(OC)/6800(OC),7000(OC)/7200(OC)/7600(OC),7800(OC)/8000(OC)MHz Memeroy Frequency
DISPLAY
1x HDMI™port up to support 4096x2160@30Hz resolution (support HDCP2.2)
1 DP interface with a maximum resolution of 4096x2160@60Hz.
EXPANSION SLOT 1x PCIe 5.0 x16 slot
1x PCIe 4.0 x4 slot
1x PCIe 3.0 x1 slot
STORAGE 1*M.2 slot ((2280/22110 PCIE X4/X2 channel SSD only),
4x SATA 3.0 ports
USB Onboard rear ports: 4* USB3.2 GEN1 ports, 4* USB2.0 ports,and and 1 USB Type-C (10Gbps) port Board pins: 1 set (2) USB2.0 pins, 1 set (2) USB3.2 GEN1 pins, 1 front USB Type-C (10Gbps) port
LAN Realtek® RTL8125BG NIC Chip
AUDIO Realtek® ALC897 Codec
INTERNAL I/O 1x 24-pin Power Connector(ATX_PWR)
1 8PIN motherboard ATX 12V power port with 12V input
1x CPU Fan
2x System Fan
1x PS/2 interface
1x M.2 slots (Key-M)
4x SATA 6Gb/s ports
1x 4-Pin SPEAKER
1x Front Audio
1x COM_A Port
1x 9-Pin DEBUG_CON
1x CLR CMOS
SSD 1* M.2 4.0 slot (supports 2242/2280 PCIE X4/X2 channel SSD only)
3* SATA3.0 ports
OPERATING SYSTEM Support for Windows® 11 64-bit, Windows® 10 64-bit
FORM FACTOR M-ATX
245mm x 245mm
