6 phase high specification power supply
Alloy power supply heat sink module
Low Temperature Mos
High-speed M.2 SSD
Dual display interface HDMI, VGA
TECH SPECS:
CHIPSET INTEL H610
CPU Supports 12th/13th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors
LGA 1700
MEMORY 2x DDR4, Maximum Memory Capacity 64GB
Memory Support DDR4 3200(OC)/ 2933(OC)/ 2666(OC)/ 2400(OC) MHz
Supports Intel® XMP 2.0 OC
Supports Dual-Controller Dual-Channel mode
ONBOARD GRAPHICS 1x VGA
*Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz
1x HDMI™port
*HDMI™ port supports up to 4K@30Hz
*Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
EXPANSION SLOT 1x PCIe 4.0 x16 slot
1x PCIe 3.0 x1 slot
STORAGE M.2 slot (Key M), type 2242/2280 (supports PCIe 3.0 x4 mode)
3x SATA 6Gb/s ports
RAID Not Supports RAID
USB *Front USB (Total 4 ports)
2x USB 3.2 Gen1 Type A
2x USB 2.0
*Rear USB (Total 6 ports)
2x USB 3.2 Gen1 Type A
4x USB 2.0
LAN Realtek® RTL8111H 1G LAN
AUDIO Realtek® ALC897 or CONEXANT® CX20632
5.1-Channel High Definition Audio
INTERNAL I/O 1x 24-pin Power Connector(ATX_PWR)
1x 8-pin Power Connector(CPU_PWR)
1x CPU Fan
1x System Fan
1x M.2 slots (Key-M)
3x SATA 6Gb/s ports
1x CLR_CMOS
1x 4-Pin BUZZER
1x Front Audio
1x COM_A Port
LED FEATURE 4x Side-by-Side Debug LED
OPERATING SYSTEM Support for Windows® 11 64-bit, Windows® 10 64-bit
FORM FACTOR M-ATX
225mm x 180mm
